MIL-PRF-62411/2A(AT)
PRESSURE SOURCE.
NOTE: PROOF PRESSURE MAY BE PNEUMATIC OR
HYDROSTATIC.
BURST PRESSURE SHALL BE PNEUMATIC.
VENT
SHUTOFF VALVE (TYP)
PRESSURE GAGE
ONE HOT AIR
PORT CONNECTED TO A PRESSURE
SPOURCE -
CHAMBER
PRESSURE MAY BE
TEMPERATURE
APPLIED TO EITHER HOT AIR PORT.
THERMOCOUPLE
SAFETY CHAMBER
(OVEN FOR BURST
PRESSURE TEST)
DEICING AIR
PORT CAPPED
CONDITIONED
AIR PASSAGES
OPEN
UNIT TEMPERATURE
THERMOCOUPLE
(BURST TEST
ONLY)
HOT AIR
PORT CAPPED
FIGURE 5. Proof and burst pressure test setup.
9
