MIL-PRF-62411/2A(AT)
PRESSURE REGULATED
ROOM TEMPERATURE
AIR OR NITROGEN
PRESSURE SOURCE.
SHUTOFF
VENT
VALVES
CONDITIONED AIR PORT OPEN.
SMALL AMOUNT OF LEAKAGE FROM CONDITIONED
AIR INLET OR OUTLET IS
PRESSURE
ACCEPTABLE, SUBJECT TO THE LIMITS
GAGE
SPECIFIED FOR THE INTERNAL
LEAKAGE TEST.
WATER
FILLED
ONE HOT AIR
TANK
PORT CONNECTED
TO A PRESSURE
SOURCE -
PRESSURE MAY BE
APPLIED TO EITHER
HOT AIR PORT
HOT AIR PORTS
CAPPED
CONDITIONED
AIR PORT
OPEN
HOT AIR
NO LEAKAGE ALLOWED FROM
PORT CAPPED
SIDEPLATES,
HOT AIR PANS, OR WELDS
FIGURE 4. Leakage test setup.
8
