MIL-PRF-62411/3A(AT)
PRESSURE SOURCE.
NOTE: PROOF PRESSURE MAY BE PNEUMATIC OR
HYDROSTATIC.
BURST PRESSURE SHALL BE PNEUMATIC.
SHUTOFF VALVE (TYP)
VENT
PRESSURE GAGE
PRECOOLER
CHAMBER
TEMPERATURE
TEMPERATURE
THERMOCOUPLE
THERMOCOUPLE
(BURST TEST ONLY)
SAFETY CHAMBER
(OVEN FOR BURST
PRESSURE TEST)
POSITIVE
RESTRAINT
FOR SLIP-
FIT CAP
BLEED PORT
CAPPED AND
CONNECTED TO
PRESSURE SOURCE
FAN AIR
BLEED PORT
PASSAGES OPEN
CAPPED
FIGURE 5. Proof and burst pressure test setup.
8
