MIL-PRF-53047B
also be provided. The instructions shall be on a durable material capable of surviving all operating
and storage conditions applicable to the water chiller.
3.8.3 Labeling. All connections, controls, and displays shall be labeled. Guidance is provided
by MIL-HDBK-759.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as
follows:
a. First article inspection (see 4.2).
b. Conformance inspection (see 4.3).
4.2 First article inspection. First article inspection shall be performed on one complete unit
(see 6.3) when a first article is required. This inspection shall include the examination of 4.4 and
the tests of 4.5.
4.3 Conformance inspection. Inspection of production units shall include the examinations of
4.4 and the tests specified in 4.5.11.
4.4 Examination. Each unit shall be physically examined for compliance with requirements
specified in 3.3 to 3.8.3. This element of inspection shall encompass all examinations of
performance, safety, human engineering, and dimensional requirements. Non-compliance with
any specified requirement, or the presence of one or more defects lessening required efficiency
shall constitute cause for rejection. Each unit shall be examined for the defects specified table II.
TABLE II. Inspection requirements.
Item
Reqt para
Defect
Examination
101
3.3.1
Physical characteristics not as specified.
Visual/Doc.
102
3.3.1.2
Dimensions not as specified.
Visual/SIE
103
3.3.1.3
Weight not as specified.
Visual/SIE
104
3.3.1.4
Structural support not as specified.
Visual/SIE
105
3.3.2
Engine not as specified.
Visual/Doc.
106
3.3.3
Water pump not as specified.
Visual/Doc.
107
3.3.4
Water cooler not as specified.
Visual/Doc.
108
3.3.5
Electrical system not as specified.
Visual/Doc.
109
3.3.5.1
Batteries not as specified.
Visual/Doc.
110
3.3.5.2
Slave start connector not as specified.
Visual/SIE
111
3.3.6
Operational control panel not as specified.
Visual
112
3.3.7
Input/output water control panel not as specified.
Visual/SIE
113
3.3.8
Ancillary items not as specified.
Visual/Doc.
114
3.3.8.9
Storage provisions not as specified.
Visual
115
3.6
Interface requirements not as specified.
Visual/Doc.
116
3.7.1
Materials not as specified.
Doc.
11
